Handheld Nylon Cable Tie Machine Zip Tie Gun - X-WM06A Pistol Car Type
Interested in this machine? Get a quote now!
Please send an EMAIL to: kevin@cablecutting.net or fill out the inquiry form below.
Inquiry Now
Product Description
Features:1.The disordered bulk cable ties flow into random vibration plate, cable ties piped through to tips.2.Pull the trigger, automatic feeding, tape, tightening, cutting, polishing wastes and all other actions;3.0.7 seconds to complete all actions including feeding, tape, tightening, cutting, polishing wastes, also including auxiliary time, the whole cycle a total of about 1.3 seconds.A machine can replace 7-8 workers. A year can save wage costs over 20 million;4.Waste collected automatically in a waste box via a dedicated recovery system (optional);5.Hand held tip lightweight ,compact design grip, easy to hold, long-term use will not feel tired;6.Tying the intensity or tension can be adjusted by the knob;7.Host body own PLC control system, touch screen Chinese /English display, simple operation;8.In automatic production line can be conjunction with robot to achieve fully automatic cable tie,Also it can be fixed to the table using as the desktop cable tie machine.
Specification
Model | X-WM06A |
Type | Handheld tie gun |
Cable tie length | 80/100/120/150 mm (can be customized) |
Tension force | >20N |
Tying Bundle Diameter | 1mm - 30 mm |
Rest length after cutting | 1-3MM |
Tying speed | 0.5 s/pc |
Compressed air connection | 0.55 - 0.65 MPa |
Power supply | 110, 220 V (50 - 60 Hz) |
Dimension | 650 * 650 * 720 mm |
Weight | 130 kg |
| Brand Name | X cable Tech |
| Cable tie length | 80/100/120/150 mm (can be customized) |
| Compressed air connection | 0.55 - 0.65 MPa |
| Dimension | 650 * 650 * 720 mm |
| Function | Cable Tying |
| Model Number | X-WM07A |
| Place of Origin | Guangdong;China |
| Power supply | AC220V/110V 50/60HZ |
| Rest length after cutting | 1-3mm |
| Tying Bundle Diameter | 1mm - 30 mm |
| Tying speed | 0.5s/pc |
| Type | Handheld tie gun |
| Usage | Binding |
| Weight | 130kg |
