Customizable Cakes Vertical Type Baby Nipples Plastic Injection Moulding Machines
Price in reward points: 80400
- Brand: JIEYANG
- Product Code: CN230813476030
- Availability: 500
Product Description
| Customizable Sell Like Hot Cakes Vertical Type Baby Nipples Plastic Injection Moulding Machines |
| MODEL | UNIT | FJY-253 1600R2 | |||
| Injection Unit | Screw Diameter | mm | 45 | 50 | 55 |
| Injection Pressure | kg/cm2 | 2226 | 1803 | 1490 | |
| Max.Shot Weight(PS) | g | 300 | 371 | 449 | |
| Injection Stroke | mm | 200 | |||
| Clamping Unit | Clamping Force | Tons | 160 | ||
| Rotary Table Size | mm | 1380 | |||
| Max.Open Distance | mm | 600/700 | |||
| Min.Mold Height | mm | 300/400 | |||
| Opening Stroke | mm | 300 | |||
| Enjection Force | Tons | 4.6 | |||
| Enjection Stroke | mm | 100 | |||
| Power Unit | Max.Hydaulic Pressure | kg/cm2 | 140 | ||
| Pump Motor Power | KW/HP | 22/30 | |||
| Total Power | KW | 36 | |||
| Other | Machine Weight | Tons | 9.2 | ||
| Machine Dimensions(LxWxH) | m | 2.9*2.2*3.85 | |||
| After-sales Service Provided | Engineers available to service machinery overseas |
| Applicable Industries | Manufacturing Plant;Hotels;Garment Shops;Building Material Shops;Machinery Repair Shops;Food & Beverage Factory;Farms;Restaurant;Home Use;Retail;Food Shop;Printing Shops;Construction works;Energy & Mining;Food & Beverage Shops;Other;Advertising Company |
| Brand Name | JIEYANG |
| Condition | New |
| Core Components | Bearing;Motor;Pump;Gear;PLC;Other;Pressure vessel;Engine;Gearbox;Screw |
| Ejector Force(kN) | 45 kN |
| Ejector Number | 3 |
| Ejector Stroke(mm) | 100 mm |
| Injection Rate (g/s) | 261 g/s |
| Injection weight | 449g |
| Injection Weight (g) | 449 g |
| Key Selling Points | Competitive Price |
| Machine Color | Customized |
| Machine Dimensions(LxWxH) | 2.9*2.2*3.85m |
| Machine Type | Hydraulic |
| Machine weight | 9.2Tons |
| Machinery Test Report | Provided |
| Marketing Type | Hot Product |
| Max.Open daylight | 600/700mm |
| Min.Mold Height | 300/400mm |
| Mold Height(mm) | 300 - 400 mm |
| Open Stroke(mm) | 300 mm |
| Opening stroke | 300mm |
| Place of Origin | Guangdong;China |
| Plastic Processed | ABS;ABS/PP;EPS;EVA;EVOH;FRPP/PVC;HDPE;HDPE/PP;LDPE;MLLDPE;PA;PC;PE;PE/PP;PET;Polystyrene;PP;PPR;PVC;Other |
| Plastic Type | Thermoplastic |
| Power (kW) | 22 kW |
| Screw diameter (mm) | 55 mm |
| Screw Speed (rpm) | 0 - 250 rpm |
| Showroom Location | Viet Nam |
| Style | VERTICAL |
| Theoretical Shot Volume(cm³) | 475 cm³ |
| Type | Tube Shoulder Injection |
| Video outgoing-inspection | Provided |
| Warranty | 1 Year |
| Warranty of core components | 1 Year |
| Weight (KG) | 9200 kg |
