25khz/45khz 60W Dual Frequency Ultrasonic Transducers For Ultrasonic Washing Machine

Price in reward points: 30
  • Product Code: CN230812857768
  • Availability: 500
- +

Products Description
Ultrasonic transducer is to convert electrical energy into sound energy which also is called ultrasonic.it is composed of outer shell,matching tier,ring piezoelectric ceramic,backing material,outgoing cable and cymbal. The characteristics of transducers depend on material selection and manufacturing process. The performance and service life of transducers of the same size and shape are very different.

Main Features:

1: High mechanical Q value.
2: High transfer efficiency.
3: High quality piezoelectric ceramic material with good heat resistence.
4: Large range of working temperature.
5: Lower resonant Impedance.
6: Large amplitude,high vibration speed.
7: Clean and tidy appearance,without corrosion,deformation and scratch.
8: Frequency and static capacitance keep more consistency.
9: High output power.
10: ight with bolt ,be easy to install,reliable .


•Strong cavitations,powerful and effective, quick detergence.
•Automotive and aerospace industry,mechanical industry,plating industry etc.
25K/45K-60W P4 Ultrasonic Transducer
Static Capacity(pF)(±10%):5200
Resonance Impedance(Ω):10-20Ω
Input Power(W):60W
Piezoceramics size:38*15*5(pzt4)
Radiating Diameter:62mm
After Warranty ServiceVideo technical support
Applicable IndustriesHotels;Garment Shops;Building Material Shops;Manufacturing Plant;Machinery Repair Shops;Food & Beverage Factory;Farms;Restaurant;Home Use;Retail;Food Shop;Printing Shops;Construction works;Energy & Mining;Food & Beverage Shops;Advertising Company
ApplicationCleaning Machine
Frequency25/40KHz +/- 1KHz
Machinery Test ReportProvided
Marketing TypeOrdinary Product
Piezoceramics size38*15*5(pzt4)
Place of OriginBeijing;China
Product nameDouble Frequency Sensor Cleaner Pzt Ultrasonic Transducers
Radiating Diameter64mm
Showroom LocationViet Nam;Indonesia;India;Russia
Static Capacity5200pf±10%
TypeUltrasonic Transducer
Video outgoing-inspectionProvided
Warranty1.5 years
Weight (KG)0.6
